MAIN CHARACTERISTICS

Builder: AB Yachts (Next Yacht Group – Italy)

Model: AB Yachts 80

Hull Number: 206

Naval Architecture & Exterior Design: Next Yacht Group

Interior Designer: Marco Casamonti (Studio Archea, Florence, Italy)

Type: Motor Yacht / Sport Yacht / Sportbridge / Open / Performance Yacht

Hull Type: Deep V / Planing / Fast Yacht

Hull Material: GRP / Kevlar

Superstructure Material: GRP / Kevlar

Decks: Teak

Year: 2025

Length Overall: 25.20 m (82’ 8”)

Waterline Length: 23.97 m (78’ 8”)

Beam: 6.50 m (21’ 4”)

Max Draft: 1.30 m (4’ 3”)

Displacement (full load): 75,000 kgs (165,347 lbs)

Gross Tonnage: 100 GT

CE Certificate Design: Category A

Class Certificate: RINA C ✠ HULL • MACH Y - Unrestricted Navigation

CONSTRUCTION

Hull: GRP with Kevlar reinforcements and Divinycell coring, vacuum bagged and laminated with Vinylester-Epoxy resins

Superstructure: GRP with Kevlar and Carbon reinforcements and Divinycell coring, vacuum bagged and laminated with Vinylester-Epoxy resins

Decks: Teak-laid (10mm)

PROPULSION

Type/ Fuel: Triple Waterjets Diesel

Main Engines: 3 x 2000 Hp (1471 kW) MAN V12-2000 @ 2300 RPM

Transmissions: 2 x MJP steerable waterjets + 1 x MJP central booster waterjet

Gearboxes: 3 x ZF with optimized reduction ratio

Maximum Speed: 55 knots

Cruising Speed: 49 knots

Range: 450 NM (@ Cruise Speed)

TANKAGE

Fuel Capacity: 9,000 l (2,377.5 US Gallons)

Fresh Water Capacity: 1,800 l (475.5 US Gallons)

ACCOMMODATION

Up to 8 Guests in 4 en-suite staterooms (4 bathrooms with en-suite shower rooms)

Guest Cabin Configuration:

• Master Cabin: Double cabin with en-suite bathroom and walk-in closet located amidships
• VIP Cabin: Double cabin with closets and en-suite bathroom located forward
• Twin Guest Cabin: Twin cabin to portside with closet and en-suite bathroom
• Bunkbed Cabin: Single and folding bed cabin to starboard side with closet and en-suite bathroom

Main deck with lounge saloon, formal dining area, designer fully equipped galley, day-head, crew mess and wheelhouse

Crew Accommodation:

• 1 Crew cabin for 2 with bunkbeds and 1 bathroom and separate exit to outside deck

MAIN EQUIPMENT

Generators: 2 x 28 kW KOHLER each mono-phase (MED) / 32 kW bi-phase (U.S.A.)

Electric Circuits: 240V bi-phase 60Hz (U.S.A.) / 240V 50Hz EU

Air Conditioning: FRIGOMAR 140.000 BTU

Stabilizer System: SEAKEEPER Gyroscopic stabilizer mod. 18 working at anchor (“zero speed”) and in navigation (“underway”)

Bow thruster: Electric thruster, SIDE POWER 240V

Watermaker: 180 l/h IDROMAR

HOUSEHOLD APPLIANCES

Galley:

• MIELE cooker hood 60cm
• MIELE induction hob 60cm
• MIELE oven 60cm
• MIELE dishwasher 45cm
• Sink (40x40cm)
• Fridge/refrigerator 180cm

NAVIGATION & COMMUNICATION EQUIPMENT

3 x MAN MMDS electronic engine displays

MJP waterjet joystick control

On the raised pilothouse’s helm station:

• Monitoring system
• SIMRAD (1) monitor 24” + (2) monitors 19”
• SIMRAD radar Halo 24
• SIMRAD echosounder (graphic)
• AIRMAR transducer (log, speed, temp) data only
• SIMRAD autopilot
• SIMRAD AIS
• SIMRAD VHF
• AIRMAR weather Station
• 2 x SIMRAD GPSs

Mini-station on flydeck:

• VHF SIMRAD remote handset
• Multifunction colour display 4.1” mod. IS42 (for data only)

AUDIO-VIDEO SYSTEM

The audio-video system is SAMSUNG with CRESTRON music control via APPLE iPad for an easy and more intuitive use for all guests on board (as follows):

Master Cabin:

• 1 x SAMSUNG TV 43" 4K
• 1 x Mini iPad Apple 6 Wi-Fi 64GB (configuration with CRESTRON)
• 1 x Decoder Owner’s supply
• 1 x HDMI wall plate
• 2 x Speakers 6,5” P4-W65 – rectangular
• Streaming: NETFLIX & DISNEY+ with Smart TV, Spotify, Airplay 2 with BLUESOUND amplifier

VIP Cabin (x1), Guest Cabins (x2) equipment list per cabin:

• 1 x SAMSUNG TV 32" Full HD
• 1 x Mini iPad Apple 6 Wi-Fi 64GB (configuration with CRESTRON)
• 1 x Decoder Owner’s supply
• 1 x HDMI & USB wall plate
• 2 x Speakers 6,5” P4-W65 – rectangular
• Streaming: NETFLIX & DISNEY+ with Smart TV, Spotify, Airplay 2 with BLUESOUND amplifier

Main Saloon:

• 1 x SAMSUNG TV 65" 4K
• 1 x Mini iPad Apple 6 Wi-Fi 64GB (configuration with CRESTRON)
• 1 x Decoder Owner’s supply
• 1 x HDMI wall plate
• 5 x Speakers 6,5” P4-W65 – rectangular
• Streaming: NETFLIX & DISNEY+ with Smart TV, Spotify, Airplay 2 with MARRANTZ Cinema 60 amplifier
• 1 x B&G ASW-608 subwoofer

External Areas (aft deck, bow and sundeck):

• 6 x JL-Audio waterproof Speakers 770 Luxe 7,7” included (2 x aft deck, 2 x bow area, 2 x flydeck)
• 1 x Powersound MEZZO 2-channel amplifier in each area
• 1 x BLUESOUND streaming player for each area with Airplay 2 and Spotify connect streaming

IT & Wi-Fi

1 x PEPLINK 4G router – Wi-Fi - worldwide - LTEA and Wi-Fi receiver for Marina hotspot communications

1 x UBIQUITY Dream Machine Pro Router wireless controller, Firewall

1 x UBIQUITY with 48 POE switch for all physical ethernet connections

4 x UBIQUITY Access Point UniFi 6 Long-Range 3000 Mbit/s PoE (distributed across all decks)

2 x POYNTING Marine & Coastal Wi-Fi Gain 9dBi

2 x POYNTING Marine & Coastal LTE/5G Gain 9dBi

Wi-Fi Network

CCTV

3 x LILIN Z5R6422XR 2-megapixel outdoor dome with IT LED Camera

1 x LILIN NVR6104E 4cH PoE standalone network video recorder

OPTIONAL EQUIPMENT INCLUDED

Class RINA C ✠ HULL • MACH Y - Unrestricted Navigation (Pleasure)

Metallic Rover Left Tempes grey Met superstructure

Metallic Rover Mud Aspen Silver Met hull

Teak on flydeck

Outdoor tent on aft and bow complete with Carbon Fibre poles and micro – perforated technical fabric tent

Side garage and haulage/launching system for tender

180 l/h Watermaker IDROMAR (upgrade from std 130 l/h)

Gyroscopic stabilizer SEAKEEPER mod. 18 working at anchor (“zero speed”) and in navigation (“underway”)

Monitoring system

AIS and weather station

Crew Mess equipped with:

• Monitoring system redundancy
• TV
• CCTV vision

Aft third control station

4 x Underwater lights on the transom

Portholes sensors

Electric blind curtains in the saloon

Electric blind curtains in the lower deck’s accommodations

Electric black-out rollers in the lower deck’s accommodations (Owner, VIP & Guest cabins)

Electric bow thruster

Gensets’ Parallel system

Seamless Transfer: No-power-blackout smart technology in order to avoid the blackouts from switching the genset power onto the shore power supply, and vice versa

Night vision camera predisposition only

Day head on main deck

Mini Pilot station on the flydeck

TENDERS

Tender 3.45 meters (3.95m deflated) + Jet ski (personal watercraft) not included

OTHER OPTIONALS

For any other possible item or custom request, the Shipbuilder will evaluate the feasibility and in case will provide a quotation.

On request.

Spring 2025.

5 Years on the hull, 2 years on the rest of the ship’s systems.

Will be showcased at 2024 Cannes Yachting Festival.

Berth place management possible on French or Italian Riviera as well as Spain (Mainland and Balearic Islands), Greece and Turkey.

These particulars are given in good faith as supplied to us but cannot be guaranteed and cannot be used for contracts.
