ELECTRONICS, HIFI

TV 37" in the telescopic saloon
Raymarine navigation pack with screen and i70 box at the chart table and Fly (update will be done first semester of 2025)
Radar at the chart table and Fly
Pilot remote control at the chart table
Autopilot hydraulic part, serviced October 2021
VHF Raymarine 240E at the chart table and Fly
Portable Motorola lrridium + mobile antenna
Raymarine wind vane, replaced June 2020
6 Scheiber modules replaced (remote control of lights) June 2020
Navtex
AIS Raymarine Tx/Rx 650
Sonar Simrad with B&G Zeus 3 display with integrated Gps & Med mapping
Hertzian TV antenna
2 rear view cameras for maneuvering, positioned under the Fly

LIGHTING, VARIOUS 12V / 24V

Tricolour lights and anchor lights at the head of the mast
Navigation lights on balconies and Fly
1 deck light
2 Spreader lights
2 underwater lights located aft
Engine compartment and GE lighting
12V lighter at the chart table
2 inflatable canoes
2 inflatable paddles


GE LOCAL
3rd freezer 220v

MISCELLANEOUS, SAFETY
Complete sanding hulls, March 2021
Last antifouling done in June 2024


MAIN ANCHOR

Anchor SPADE 75Kg
100m of chain diam 14 needs to be replaced
2nd anchor Spade 55 Kg
Ropes and fenders
HIGHFIELD dinghy 460 + HB Honda 60HP (2022), all serviced in 06/2024
Safety equipment for 12 pax
2 lifeboats last revision 09/2021, next one scheduled for January 2025
1 rising water alarm per hull
Fire extinguishers, revision December 2024

FITTINGS, DECK EQUIPMENT

2 large front trampolines replaced in February 2021
Batilyne anti-uv protection of the roof windows (white)
Windlass 2000W 24V with wired remote control, motor and gearbox replaced August 2021
1 electric mainsail halyard winch 74.2 Harken (mechanical part totally restored in October 2022)
3 electric winches for sheets & maneuvers 74.2 Harken (mechanical part totally restored in October 2022)
Gennaker fittings with bowsprit
2 aft mooring capstans
Ladder for accommodation
Removal/replacement of the 6 side portholes of the hulls: January 2021
Repair of the Sika joints between hull and deck: January 2021
Repair of the Sika roof/deck joints: January 2021
Replacement of 13 worn hull passes and bronze valves: January 2021
Removable sun canopy under staysail/GE, overhauled October 2021
Tenderlift rear platform, removal/overhaul/replacement of straps February 2021


COCKPIT, TRANSOM

Doors to cockpit sliding glass window type (3 parts) in white lacquered aluminum
Large cockpit fitted with extended varnished teak table (+2 place settings) + protective cover
Teak slatted cockpit floor

TRANSOM :
Teak slats, sanded in January 2021
Stainless steel swim ladder
Shower hot/cold, one for each hull, luxury model stainless steel frame April 2021
Stainless steel handrails

COCKPIT located under the flybridge
Table with extension, 8 people
Courtesy lights
Storage boxes in the benches
Teak cabinet with sink and refrigerator
Built-in plancha
4 folding teak chairs
Rear beam with storage + sunbathing area + protective cover
4 fishing rod holders

FLYING BRIDGE

2 helm stations with engine & thruster controls
Cushions and backrests of benches, fabrics replaced in March 2021 + protective cover
Windlass control replaced in June 2020
Storage
Sunbathing, 3 large cushions under the boom, fabric replaced in March 2021
Bimini extra large, fabric replaced in March 2021
Manual Fly closure
Teak floor in Fly
Refrigerator in Fly
Removable sun awning under boom, revision October 2021

LAGOON 620 BUILT IN 2012 AT LAGOON’S MANUFACTORY

Designer VPLP

MALTA FLAG – Annual tax 3200€/year
VAT PAID

Insurance Europe, annual premium :
- P&I 4500 euros
- Hull & machinery 7000 euros
Onshore storage Marseille/Corbière 1400 euros/month

Hull Number : 49
LOA : 18,90 m
BEAM : 10 m
DRAFT : 1,55 m
AIR DRAFT: 31 m
Mainsail: 146 m2
Genoa : 91 m2
Max sails : 231 m2
Fuel capacity : 2x650L
Displacement : 42 T

MAINTAINED BY PROFESSIONAL AND ALWAYS LOOKED AFTER BY ONBOARD SKIPPER

--------------------------------------------------------------------

LAGOON 620 BUILT IN 2012 AT LAGOON’S MANUFACTORY

Designer VPLP
MALTA FLAG – Annual tax 3200€/year
VAT PAID
Insurance Europe, annual premium :
• P&I 4500 euros
• Hull & machinery 7000 euros
Onshore storage Marseille/Corbière 1400 euros/month
……
Hull Number : 49
LOA : 18,90 m
BEAM : 10 m
DRAFT : 1,55 m
AIR DRAFT: 31 m
Mainsail: 146 m2
Genoa : 91 m2
Max sails : 231 m2
Fuel capacity : 2x650L
Displacement : 42 T
…..
MAINTAINED BY PROFESSIONALS and ALWAYS LOOKED AFTER BY ONBOARD SKIPPER

2 VOLVO D3 ENGINES - 150 HP (REPLACED IN 2021)
Access to the machine room through 2 large covers on jacks
Water recovery tank
Forced extraction
2 ZF reduction gears :
- Port side reconditioned in June 2020
- Starboard reconditioned in October 2021
2 propellers 4 blades March 2021
Replacement of the 2 TIDESMARINE glands
Electronic engine control unit, 1 per hull
Upper rudder bearings September 2022
Lower rudder bearing May 2024
Engine hours: 2908 h

PLUMBING, TANKS

2 aluminum GO tanks for 1300L
2 fresh water tanks for 960L
2 water heaters of 63L RESISTANCES 05/2020
2 water groups 24V under pressure
Fresh water dock outlet on port side
2 manual bilge pumps and 2 electric pumps in the hulls
1 electric pump per engine hold
1 black water tank 72L per toilet (except crew cabin on port side)
Tecma electric fresh water toilet
GO transfer pump

Watermaker Sea Recovery 260L/H
Hours Watermaker 3000 h
SERVICED 05/2024
Spare watermaker 200L/H (not connected)

ELECTRICITY, COMFORT

Electrical circuits :
Power 220V/S0HZ AC
Comfort 24V DC (Domestic)
24v gel batteries:
4 x 100A June 2023
4 x 100A June 2024
220V outlets in all cabins, saloon, galley, engine room, GE room, forward points
2 x 220V S0HZ shore power + 2 cables
2 engine batteries 12V 50A - March 2020 and June 2024
2 24v Mastervolt alternators - June 2020
12V S0A emergency starting battery for generator or MP annex
1 Mastervolt S000W 24V /220V inverter - June 2019
1 Cotek 2000W 24V /200V inverter - June 2022
2 Mastervolt 100A chargers (2019 and 2023)
1 Cotek 2000W 24V /200V converter - June 2019
ONAN 17.5 KVA generator, 4 shock absorbers replaced June 2019, revision done in June 2024
Generator battery 12v from July 2024
Generator hours : 10.000 h
Many spare parts:
- Spare Jabsco fresh water unit
- 220v desalination pump
- Toilet motors

RIG
Removal of mast and inspection in October 2022
White Aluminium mast
Carbon boom canoe white with lights for flybridge
Genoa forestay from June 2019
Staysail forestay from June 2020
Shrouds from January 2021
Running rigging replaced in November 2021 (halyard, sheets)
Adjustment and sea trials after rig replacement in May 2021

SAILS

Hydranet mainsail battened (ref. HR 433) 146 m2, December 2021
Main sail cover, May 2020, adapted to the new main sail from March 2024
Hydranet genoa 91m2 serviced in March 2024
Furling system Genoa from June 2019
Tri radical cut Mylar gennaker 190m2 with furling system, serviced in March 2021
Staysail on furling system, serviced in March 2024

--------------------------------------------------------------------

RIGGING
Fully removed and inspected in October 2022
White lacquered aluminium mast
White lacquered carbon boom canoe with flybridge lights
Genoa forestay June 2019
Staysail forestay June 2020
Shrouds & lower shrouds January 2021
Running rigging replaced in November 2021 (main halyard, sheets ...)
Adjustment and sea trials following rig replacement, May 2021

SAILS

Battened mainsail in hydranet (ref. HR 433) 146 m2, December 2021
Mainsail cover, May 2020, adapted to the new mainsail March 2024
Hydranet genoa 91m2 serviced March, serviced March 2024
Electric furling system for genoa June 2019
Tri-radial Mylar gennaker 190m2 on furler, serviced March 2021
Staysail on electric furler, serviced March 2024

>> 5 CABINS VERSION (4 DOUBLE CABINS + 1 CABIN WITH BUNK BEDS)
>> Air conditioning 96000 BTU/2 compressors: Serviced in June 2023
>> Cabin, galley and saloon fans

INTERIOR DESIGN

Woodwork in Alpi light oak
Dark color floor in Wenge
Leather upholstery
Pleated blinds throughout the boat, including cockpit access window

GALLEY

Panoramic central island:
Double stainless steel sink
5 burner gas stove replaced in May 2021 + 4 gas bottles (fiberglass)
Repair of drawer doors with replacement of locking systems, thicker wood panels, March 2021
Refrigerator 220v
Freezer 220v
Electric oven
Microwave oven with grill
Additional refrigerator
Extractor hood
Dishwasher 12 PAX 2023
Washing machine/dryer SMEG 5 kg, 04/2020
Lots of storage space

SALOON

On starboard Side with L-shaped seat
2 air-conditioning units
2 coffee tables convertible into dining table (electric)

MAP TABLE on the bow with electrical panels and equipment

PORT HULL
CABINS

Aft port cabin

Bed 160X205 (convertible into 2 single beds 90*205)
Mattresses replaced in May 2021
Storage and closet
Opening on the aft skirt
Bathroom with separate shower
Deck hatches and porthole
1 air heater for air conditioning

Central cabin

2 bunk beds 90X205
Mattresses replaced in May 2021
Office with storage
Deck panels and porthole
Private bathroom with double access
Separate shower
1 air heater for air conditioning

Forward passageway: Combi Fridge freezer LIEBHERR 200L/60L replaced in April 2020 Port forward cabin VIP:

Bed 160X205
Mattresses replaced in May 2021
Deck panels and porthole
Private bathroom
Separate shower
1 air heater for air conditioning

Crew cabin forward point

Single bed
Mattresses replaced in May 2021
Sink
Shower
Manual toilet
Hull window
Access to opening deck panel with curtain
1 air heater for air conditioning

STARBOARD HULL

Aft owner's cabin
Bed of 160X205
Mattresses replaced in May 2021
Numerous storage spaces, drawers and equipment
Large dressing room and library
Dressing table
Sofa 2 places
Opening on private back skirt with stairs
Independent WC
2 air-conditioning units

Forward cabin starboard VIP

Bed of 160X205
Mattresses replaced in May 2021
Office with storage and bookcase
Deck panels and porthole
Private bathroom with double access
Separate shower
1 air heater for air conditioning

Starboard forepeak and numerous shelves for storage

--------------------------------------------------------------------

>> 5 CABINS VERSION (4 DOUBLE CABINS + 1 CABIN WITH BUNK BEDS)
>> Air conditioning 96000 BTU/2 compressors: Serviced in June 2023
>> Cabin, galley and saloon fans

INTERIOR DESIGN

Woodwork in Alpi light oak
Dark color floor in Wenge
Leather upholstery
Pleated blinds throughout the boat, including cockpit access window

GALLEY

Panoramic central island:
Double stainless steel sink
5 burner gas stove replaced in May 2021 + 4 gas bottles (fiberglass)
Repair of drawer doors with replacement of locking systems, thicker wood panels, March 2021
Refrigerator 220v
Freezer 220v
Electric oven
Microwave oven with grill
Additional refrigerator
Extractor hood
Dishwasher 12 PAX 2023
Washing machine/dryer SMEG 5 kg, 04/2020
Lots of storage space

SALOON

On starboard Side with L-shaped seat
2 air-conditioning units
2 coffee tables convertible into dining table (electric)

MAP TABLE on the bow with electrical panels and equipment

PORT HULL
CABINS

Aft port cabin

Bed 160X205 (convertible into 2 single beds 90*205)
Mattresses replaced in May 2021
Storage and closet
Opening on the aft skirt
Bathroom with separate shower
Deck hatches and porthole
1 air heater for air conditioning

Central cabin

2 bunk beds 90X205
Mattresses replaced in May 2021
Office with storage
Deck panels and porthole
Private bathroom with double access
Separate shower
1 air heater for air conditioning

Forward passageway: Combi Fridge freezer LIEBHERR 200L/60L replaced in April 2020 Port forward cabin VIP:

Bed 160X205
Mattresses replaced in May 2021
Deck panels and porthole
Private bathroom
Separate shower
1 air heater for air conditioning

Crew cabin forward point

Single bed
Mattresses replaced in May 2021
Sink
Shower
Manual toilet
Hull window
Access to opening deck panel with curtain
1 air heater for air conditioning

STARBOARD HULL

Aft owner's cabin
Bed of 160X205
Mattresses replaced in May 2021
Numerous storage spaces, drawers and equipment
Large dressing room and library
Dressing table
Sofa 2 places
Opening on private back skirt with stairs
Independent WC
2 air-conditioning units

Forward cabin starboard VIP

Bed of 160X205
Mattresses replaced in May 2021
Office with storage and bookcase
Deck panels and porthole
Private bathroom with double access
Separate shower
1 air heater for air conditioning

Starboard forepeak and numerous shelves for storage
