Built by: Feadship
Year: 2002
Length: 65.00m (213′ 3″)
Beam: 11.30m (37′)
Draft: 3.35m (10′ 11″)
Classification: ABS *A1, Yachting Service, AMS
Flag: Cayman Islands
Gross tonnage: 1300 t
Net tonnage: 390 t
Designer: Philippe Starck Design
Naval Architect: De Voogt Design
Interior Designer: Philippe Starck Design
Speed: 16 knots (approx)
Range: 5000nm at 12 knots 2820 at 15knots both with a 10% margin
Fuel capacity: 126,850 Litres (33,022 US Gallons)
Water capacity: 25,000 Litres (6,604 US Gallons)
Fuel consumption: 260l/h at 1200 rpm-12knots, 430l/h at 1400 rpm-14knots, 700l/h at 1600rpm-16 knots

Engines: 2 Caterpillar 2027 HP
Engine model: 3516B
Engine hours: Port: 4514hrs (5-Sep-2024)
Starboard: 4490hrs (5-Sep-2024)
Port engine: top end overhaul in Dec 18 at 4.085 hrs next overhaul due at
15.000 hrs
Stbd engine: top end overhaul in Dec 18 at 4.060 hrs next overhaul due
at 15.000 hrs
Fuel: Diesel
Propulsion: Prop Shaft
Gearboxes: Reintjes WAF 742
Serviced in November 2023, next service in 2033
Steering: Marex OS2 / Tenfjord JR2.160 / Akerboom Rudders.
Stabilizers: Koopnautic VK3575, (upgraded main electric control in 2016)
Generators: 3 Caterpillars 3406C 229kw 1500 rpm
Serial no. 1SS00448, 449, 450
Generator hours: September 2024
Port: 20.656 Center: 17.589 Stbd: 17.885
Port gen: complete overhaul April 2023 at 20.098 hrs, next overhaul at
30.000 hrs
Mid gen: top end overhaul Jan 2024 at 17.366 hrs next over overhaul at
22.000 hrs
Stbd gen: top end overhaul in Feb 2024 at 17.483 hrs next overhaul at 22.000 hrs

Electricity: Three Caterpillar alternator set mod.3406 / 215 KW
Shore power: Transformer 370-400-440V sec 400V 200KVA 50Hz
Batteries: Main Engine Port
Four Tech Power super heavy duty 200Ah 1150A EN (Apr 2022)
Main Engine Stbd
Four Varta Silver Pro Motive N9, 12V 225Ah 1150A (Dec 2023)
Generators
Two Freedom Marine M180SHD 12V 189 Ah (Aug 2021)
Emergency
Exide Marine ES2400 EQUIPMENT GEL 10X12V 2400Wh 210A (2013,
checked in 2021)
Radio
Monobloc Discover Deep Cycle AGM 4x12V 120 Ah (Aug 2021)
Air Conditioning: Heinen Hopman system with four Carlyle 06EM475600 compressors

OTHER MACHINERY
HL-CONT Plus 05 Hamann sewage treatment system (New October 2023)
H.E.M. series 40/4000 Duplex 2x17 m3/day water maker (2002)
DVZ 250 VC - Oilmaster oily water separator (2002, inspected by ABS in 2021)
Alfa Laval MMB 304S-11 fuel separator (2002)
SPX pump FRES 50-205 / ROTOR RRT 1505 11KW main fire/bilge pump (2002)
SPX pump FRES 50-205 / ROTOR RRT 1505 11KW bilge/fire pump v(2002)
HATZ 2G40 / Johnson Pump FRE 50-205 emergency diesel fire pump (2002, inspected by ABS in 2021)

Wedge Too offers accommodation for up to 18 guests in 9 cabins and 21 crew.
The Owners deck situated above the main deck and below the wheelhouse deck, offers a full owner’s suite with two cabins, his and hers bathrooms and extensive walk-in wardrobes, a private lounge, pantry, guest powder room and elevator to all decks.  A fully private forward veranda and aft deck with full on deck walk around.

The Wheelhouse deck above has a spacious wheelhouse with office, a large ensuite captain’s cabin, a guest pantry, a guest powder room, and a spacious guest saloon with open aft deck and full walk around decks.
The sun deck is totally private, offering 360° uninterrupted view,  an oval pool surrounded by sunbathing pads for approx. 20 people in comfort.

The main deck forward boast’s three ensuite VIP cabins, one of which is full width. All are totally private with large windows in the ship’s side. The main dining room for 16 guests is full width with an adjacent pantry main galley and two guest powder rooms. Fully aft on this deck is the main guest saloon which offers spectacular views through full height windows throughout. The main deck aft is spacious and offers direct access down to the swimming platform.

The lower deck offers another 4 ensuite guest cabins, a large tender garage, aft peak with guest powder room and direct access to the large swimming platform.

Forward of the mid ships engine room are the crew cabins, spacious crew mess and crew galley.
The tank deck offers a large laundry, dry stores, cool rom and freezer room.

Owners Galley and Pantry
Two MKN ovens (2002)
Eight MKN hobs  (2002)
One MKN grill top  (2002)
One MKN plate warmer  (2002)
One variable speed extractor unit (2002)
One Samsung microwave (2020)
Four stainless steel sinks (2002)
One Samsung TV (2019)
One Miele dishwasher (2010)
One dumb waiter
Three Liebherr full height refrigerators (one 2019, two 2018)
One Liebherr full height freezer (2016)
One Foster ice maker (2015)

Crew Galley Equipment
One MKN oven (2002)
Four MKN hobs (2002)
One MKN grill top (2002)
One variable speed extractor unit (2002)
One Panasonic microwave oven (2002)
One stainless steel sink (2002)
One Miele dishwasher (2002)
Two Liebherr combined fridges and freezers (2012)

Laundry Tank Deck
Three Miele professional washing machines PW5065 (2010)
One Miele professional washing machine  PWM 507 (2024)
Three Miele professional dryers  PT5135 C (2010)
One Miele professional dryer  PT5145 C (2024)

Laundry Lower Deck fore
Two Miele professional washing machines PW5065 (2010)
Two Miele professional dryers  PT5135 C (2010)

Laundry Lower Deck aft
One Miele professional washing machine PWM 908 (2021)
One Miele professional dryer  PT5135 C (2021)

Laundry Owners Deck
One Miele professional washing machine PW5065 (2010)
One Miele professional dryer PT5135 C (2012)



Seatel Intellian V100KA (2016)
Starlink Marine (2023)
Pepwave Max BR1 Pro 5G (2023)
Fortinet WIFI Form WLC50D (2016)
Kerio Control NG500 (2014)
Cisco Switch Catalist (2009)

ECDIS Navi Sailor 3.2 transas
Two radar and arpa FR-2105/2105B series Furuno 21" high resolution display
Nautopilot 5000 series
Furuno navigational echo sounder FE-700
Furuno Navtex receiver NX-500
Leica navigator MK10 gps
Furuno universal AIS FA-150
Simrad MX 612 navigation system
Sailor 6222 VHF DSC
Furuno VHF radio telephone FM-8900S
Skanti HF-SSB radio system TRP 9000

Upgraded in 2009 and later added I-Pad controls for the entertainment system.
Two Seatel 5004 satellite TVs (2013)
One Seatel 120TV satellite TV with an 120cm Reflector (2023)
One Kaleidescape server
Two Tangram WISI controls GT01W
Two digital HD decoders
ATN IP TV

VIP 1
One Technisat DVB C DIGIT HD8-C (2009)
One SKY TV box (2016)
One Octagon SF+1008 Hot Bird satellite receiver (2016)
One ARCAM amplifier SOLO Movie51 (2009)
One Kaleidescape player (2009)
One DMP-BD60 Panasonic blu-ray player (2009)
One Gaffen 6x2 HDMI switch (2009)
One Crestron processor (2009)
One Cisco Switch (2009)
One UE40 C7700 SamsungTV (2013)
One Sharp LC-121M2 in bathroom (2009)

VIP 2
One Technisat DVB C DIGIT HD8-C (2009)
One SKY TV box (2016)
One ARCAM amplifier SOLO Movie51 (2009)
One Kaleidescape player (2009)
One DMP-BD60 Panasonic blu-ray player  (2009)
One CLUX 41-AT HDMI switch (2009)
One Crestron processor (2009)
One Cisco Switch (2009)
One 32” LG TV (2009)
One Sharp LC-121M2 in bathroom (2009)

VIP 3
One Technisat DVB C DIGIT HD8-C (2009)
One SKY TV box (2009)
One ARCAM amplifier SOLO Movie51 (2009)
One Kaleidescape player (2009)
One DMP-BD60 Panasonic blu-ray player (2009)
One CLUX 41-AT HDMI switch (2009)
One Crestron processor (2009)
One Cisco Switch (2009)
One 32"LG TV (2009)
One TV display in bathroom (2002)

Banquet Hall

One Technisat DVB C DIGIT HD8-C (2016)
One SKY TV box (2016)
One Octagon SF+1008 Hot Bird satellite receiver (2009)
One ARCAM amplifier SOLO Movie51 (2009)
One Kaleidescape player (2009)
One DMP-BD60 Panasonic blu-ray player (2009)
One CLUX 41-AT HDMI switch (2009)
One Crestron processor (2009)
One Cisco Switch (2009)
One  TH50VX 100E Panasonic TV (2009)

Main Deck Lounge

One Technisat DVB C DIGIT HD8-C (2009)
One SKY TV box (2016)
One Octagon SF+1008 Hot Bird satellite receiver (2011)
One AVR 4308 Denon AV surround receiver (2009)
One Kaleidescape player (2009)
One Panasonic DVB (2009)
One CLUX 41-AT HDMI switch (2009)
One Crestron MP2E (2009)
One Crestron HD-MD8X2 (2009)
One Cisco Switch (2009)
Two 55” ACDP-240E01 Sony TVs  (2018)

Main deck aft
One TA-FE370 Sony amplifier (2002)

Owner Deck Lounge

One Technisat DVB C DIGIT HD8-C (2009)
One SKY TV box (2016)
One Octagon SF+1008 Hot Bird satellite receiver (2011)
One AVR 4308 Denon AV surround receiver (2009)
One Kaleidescape player (2009)
One Panasonic DVB (2009)
One CLUX 41-AT HDMI switch (2009)
One Crestron MP2E (2009)
One Crestron HD-MD8X2 (2009)
One Cisco Switch (2009)
One Nvidia IP player (2021)
Two  TH 50 VX 100E Panasonic TVs (2009)

Owner deck aft
One TA-FE370 Sony amplifier (2002)

Owner State I
One Technisat DVB C DIGIT HD8-C (2016)
One SKY TV box (2016)
One Nvidia IP player (2021)
One Octagon SF+1008 Hot Bird satellite receiver (2011)
One AVR-X3500H Denon (2019)
One Kaleidescape player (2009)
One DMP-BD60 Panasonic blu-ray player (2009)
One CLUX 41-AT HDMI switch (2009)
One Crestron processor (2009)
One Cisco Switch (2009)
One TH50VX 100E Panasonic TV (2009)
Two TV displays in bathroom (2011)

Owner state II
One Technisat DVB C DIGIT HD8-C (2009)
One SKY TV box (2016)
One Octagon SF+1008 Hot Bird satellite receiver (2011)
One ARCAM amplifier SOLO Movie51 (2009)
One Kaleidescape player (2009)
One DMP-BD60 Panasonic blu-ray player (2009)
One Gaffen 6x2 HDMI switch (2009)
One Crestron processor (2009)
One Cisco Switch (2009)
One 32" LG TV (2009)

Guest Cabin 1
One Technisat DVB C DIGIT HD8-C (2009)
One SKY TV box (2016)
One ARCAM amplifier SOLO Movie51 (2009)
One Kaleidescape player (2009)
One DMP-BD60 Panasonic blu-ray player (2009)
One CLUX 41-AT HDMI switch (2009)
One Crestron processor (2009)
One Cisco Switch (2009)
One 32" LG TV (2009)
One TV display in bathroom (2002)

Guest Cabin 2
One Technisat DVB C DIGIT HD8-C (2009)
One SKY TV box (2016)
One ARCAM amplifier SOLO Movie51 (2009)
One Kaleidescape player (2009)
One DMP-BD60 Panasonic blu-ray player (2009)
One CLUX 41-AT HDMI switch (2009)
One Crestron processor (2009)
One Cisco Switch (2009)
One 32" LG TV (2009)
One TV display in bathroom (2002)

Guest Cabin 3 - Guest Cabin 4
One Technisat DVB C DIGIT HD8-C (2009)
One SKY TV box (2016)
One ARCAM amplifier SOLO Movie51 (2009)
One Kaleidescape player (2009)
One DMP-BD60 Panasonic blu-ray player (2009)
One CLUX 41-AT HDMI switch (2009)
One Crestron processor (2009)
One Cisco Switch (2009)
One 32" LG TV (2009)
One TV Display in bathroom (2002)

Bridge Deck Lounge
One Technisat DVB C Digit HD8-C- (2009)
One Sky Tv Box (2016)
One Octagon SF+1008 Hot Bird satellite receiver (2011)
One Denon AV Surround receiver AVR 4308 (2009)
One Kaleidescape Player (2009)
One Panasonic DVB (2009)
One Clux 41-AT HDMI switch (2009)
One Creston HD-MD8X2 (2009)
One Cisco switch (2009)
Two  TH50VX 100E Panasonic TVs (2009)

Main Rack

Captain’s Cabin
One 50" Samsung curved TV (2016)

C Eng Cabin
One UE32M5575AU Samsung 32” TV (2009)
One RCD-M37 Denon CD receiver (2009)

ETO Cabin
One UE32T5375AUXC Samsung 32” TV (2009)
One RCD-M37  Denon  CD receiver   (2009)

Staff Cabin’s
One 19” Samsung TV (2009)
One RCD-M37 Denon  CD receiver (2009)

Crew Cabins
One 19" Samsung TV (2009)
One RCD-M37 Denon  CD receiver (2009)

Crew Mess
One UE50RU7405UXXC Samsung 50” TV (2016)
One RCD-M37 Denon  CD receiver (2009)

One Special Craft SC611, 6.5 meter semi-rigid (2002) with an inboard Mercruiser 2.8LDTronic engine, rated 38knots
One Nautica RIB 22, 6.7meter (2002) with a Yamaha 115hp four stroke out boarder (2020)
One Van Driel overhead davit, double acting (port and stbd) in tender bay

Marqiupt Sea Stair boarding ladder, 2 sections with 12 steps
Integrated hull door swim platform (serviced in 2016)
Akerboom riviera gangway (serviced in 2016)
Two Steen fore deck anchor windlasses with capstans
Two anchors of 750kg and 7 shackles chain length each
Two aft deck capstans

SAFETY
One GMDSS Simrad Axis50 handled VHF radio 3X with 3 extra batteries
Two Sailor SART II's
Twelve 4W Orizon IT23 red light rocket parachutes
Four Ikaros line throwers
One EPIRB Kannad Safepro
Twenty-five  Draeger escape hoods
Six 4W Vulcan orange smokes
Nine Elios handflares
Two Mod lifebuoys with Daniamant light
Four Survitec Zodiac MK IV liferafts to 20 man

FIRE FIGHTING EQUIPMENT
Four CO2 fire extinguishers
One water 9 ltrs fire extinguisher
Fourteen powder 2Kg fire extinguishers
Thirty-nine foam 9 ltrs fire extinguishers
Two lithium 2ltrs fire extinguishers
One lithium 6 ltrs fire extinguisher

FIXED FIRE EXTINGUISHING SYSTEM
Tender bay fixed foam sprinkler system 60ltrs
Fixed  Co2 system man galley 5Kg
Fixed Co2 system crew galley 5Kg
Fixed Co2 system engine room 86 Kg X9
Eleven fire fighting SCBA air bottles 300 BAR 6L
Four fire fighting Sigma/Scott gears with mask
Twelve fire fighting hoses
Thirteen fire fighting nozzles
One BA compressor

LIFE JACKETS AND IMMERSION SUITS
Forty-three adult life jackets
Ten child life jackets
Seventeen inflatable life vests
Four child immersion suits
Nine adult immersion suits

CCTV - (all refitted in 2016)
One  WV-SPN531A  Panasonic aft deck camera
One  WV-SPN611 Panasonic main deck port camera
One WV-SPN611 Panasonic main deck stbd camera
One WV-SW396 Panasonic mast fore camera
One WV-SW395 Panasonic mast aft camera
One  WJ-NV300 Panasonic network disk recorder
One monitor in ECR
One monitor bridge deck office
Two monitors in the crew mess

2018
Port main engine             Top end overhaul           2018     4085 Hrs.
Stbd main engine            Top end overhaul           2018     4060 Hrs.

2021
Fin/stabilizer serviced by Koopnautic
Bowthruster serviced by Holland RP

2023
Port generator                Complete Overhaul      2023     20098 Hrs.

2024
Mid generator Mid                Top end Overhaul          2024     17366 Hrs.
Stbd generator                   Top end Overhaul          2024     17483 Hrs.
Replaced the sewage treatment system            2024
