YACHT PARTICULARS

TYPE: TWIN SCREW DIESEL PLEASURE YACHT
NATIONALITY : CAYMAN ISLANDS
PORT OF REGISTRY: GEORGE TOWN
OFFICIAL NUMBER: 740633
RADIO CALL SIGN: ZCXC5

CLASS: ABS Hull =100 AS E3, Machinery: MC E3 AUT.CLASSIFICATIONNUMBER: ABS 7505524
I.M.O. NUMBER: 7360679
BUILDERS: SCHICHAU UNTERWESER AG, BREMERHAVEN
DATE OF KEEL LAID:1974
DATE OF DELIVERY:MARCH 1975
HULL NUMBER: 2254

CONSTRUCTION:
Material: STEEL
No. of Decks: Three (3)
No. of Watertight Compartments: Two (2): low/lower deck in Engine
Bulbous Bow: N/A

HELIDECK:
Dimensions: 13,6 x 23,9 = 325 M2
Location: After part of the Vessel
Compliance with ICS guidelines: Yes

TONNAGE
Gross: 1826
Net: 547
CANAL TONNAGE
Suez Gross: 1864,26 tons
Suez Net: 1247,59 tons
Panama Gross: 1547,29 tons
Panama Net: 164,42 tons
DISPLACEMENT
Fully loaded: 3353,8 T
DEAD WEIGHT
1041,0 T
LIGHT SHIP
2360,5 T

PRINCIPAL DIMENSIONS
L.O.A. : 77,40m
L.B.P. : 69,70m
Beam: 13.219 mtrs
Draft: 5,80 m
Air Draft: (Mast height 33.50 mtrs)
Keel to Masthead: 40.50 mtrs
Parallel body: 39.00 mtrs

SPEED
Maximum: 16 Knots Range/miles: 5700
Cruising: 15 Knots Range/miles: 6080
Long range: 13 Knots Range/miles: 7015

FUEL
Type: GAS OIL

MACHINERY ETC.
MAIN ENGINES
No.: Two (2) Running hours: P: 74801, S=74801
Makers: DEUTZ-AIWA
Type: RBV 12M-350
HP/RPM: 4400/430 each
Serial No.:Port 5251648 Stbd:52516477

GEAR BOXES
Makers: RENK GEAR
Type: BUS-80
Reduction: 430/148 rpm, Serial No.: P: 640415, S:640327

BOWTHRUSTER
Makers: GARBE-LAHMEYER
Type: A15/800
Capacity: 400 HP-245 Kw
Serial No: 818452

GENERATOR SETS
No: Three (3)
Engine Makers: DEUTZ
Type: BA6-M528
KW: 441 each Voltage: 380V/50 Hz
Serial No: #1 5174770, #2 5174771, #3 5174769
Generator Makers: SMBS / 110-51
Power: 441 kW Phases: 3/50
Voltage: 380V Run. Hrs: 64953,64415,65405
Serial No: #1 818451, #2 818450, #3 818449

EMERGENCY GENERATOR
Engine makers: DEUTS
Type: BF6M 716
KW: 167
Voltage: 380v V / 50 Hz
Serial No.: 5251895
Generator Makers: SMB54 / 73-34-50-60
Power: 150Kw
Phases: 3 / 50 Hz
Voltage: 380 V
Run. Hrs: 30000
Serial No: 9600-139/001

ELECTRICITY
Shore Power: 380V, AC 220 Amp / 50 Hz
Average Consumption In Port: 70 Kw for 24 Hrs
TANKS CAPACITY (litres)
Fuel: 460000 ltrs Fresh water: 350M/T
Lub. Oil: M/E + Pitch Oil: 46000 Ballast: 193 M/T
ltrs
Dirty oil: 58,3 m3
Grey water: 3 m3
Black water: ----------

ANCHORS & CHAINS
Anchor type: Spek – patentanker
Anchor Weight: 1644 kg each
Anchor Maker: Blohm & Voss AG
Chains type: K2a Stud links
Chains Length: 248,5 each
Size of links: 40mm
Location of spare anchor: N/A

WINDLASS
No : One (1)
Makers: GARBE-LAHMEYER
Capacity: 12 Tons-Pull
Serial No: ------------

CAPSTANS
No : 1
Makers: GARBE-LEHMEYER
Capacity: 6 Tons-Pull
Serial No: -------------

PROPELLERS
Makers: ZEISE-LIAAEN VERSTELL
Type: 2 Shafts twin screw variable pitch / EF115/4, Diam 4000mm
Material: Bronze
Location of spare propeller: N/A

STABILIZERS
Makers: N/A
Serial No: -----------

WATER MAKERS
N/A
Daily consumption of fresh water only the Crew 4 to 6 tons
Daily consumption of fresh water with Guests 8 to 10 tons
Makers: LIFTSTAR 600 R/Air winch
Location: Main Deck (middle port, std)
Capacity: B.W.L=0.7 tons, S.W.L=0.6 tons

LIFE SAVING EQUIPMENT
Type: Motorboat (M.B)
Makers Hatteche, Stade
Capacity: 35 persons each boat

LIFE RAFTS
No.: Two (2)
Makers: (SURVIVA)
Type: SURVIVA
Capacity: 25 persons each
Serial No: #27353SU, #27352SU
Description: Model: Projet yung, series: 2053
Particulars:
Length: 4.20m,
Weight empty: 257 Kg
Capacity: 6 persons or 450 kg,
Max.power: 50hp
